2014 Brand New 7 inch touch screen intelligent 868MHZ GSM850/900/1800/1900Mhz alarm system with remote control,PIR sensor

2014 Brand New 7 inch touch screen intelligent 868MHZ GSM850/900/1800/1900Mhz alarm system with remote control,PIR sensor,door sensor+strobe siren,rechargeable battery.

Packing list:

main unit X 1

English User manual X 1

Built-in standby battery X 1

Adaptor X 1

Remote controller X 2 ( additional 2 pcs as gifts,total:4 pcs )

Door / Window Sensor X 4

Wireless PIR Detector X 4

Wireless indoor strobe siren x 1

Function Features

• Calendar and clock function; pure GSM alarm system
• Touch screen alarm system, friendly interface 7 inch color screen displays icons and words;
• Optional languages: Up till Oct 2014, it has 8 versions of 8 languages for option: English/German/Italian/Dutch/French/Czech/Finnish/Chinese for option
• Alarm info transferring by GSM network (4 Bands: GSM 850/900/1800/1900MHz) in the form of phone call, SMS;

• Alarm info transferring by GSM network (4 Bands: GSM 850/900/1800/1900MHz) in the form of phone call, SMS;
• Alarm System has 31 wireless zones (each zone supports max 4 wireless sensors),compatible with optional wireless siren and 2 wired zones;
• In system can preset max 5 groups phone numbers, alarm call will be in first priority if a normal call is going; GSM module will send alarm info once the landline cable is cut; Every group telephone number can be individually set to transfer alarm info by SMS or phone call;
• Zone detection notification in disarm status, system can monitor the track of kids;
• In system menu you can set Pass By ON/OFF, zone type, Entry Delay ON/OFF for each zone;
• Smart-logical analysis technology, zone name, installation position and sensor name will be displayed when system alarms;
• Learn sensors into alarm host by friendly interface;
• System has non-volatile chip, information will be stored automatically if power is off;
• Optional smart functions, including check door\window status or voltage status automatically,low voltage of host or sensor alarm, uploads low voltage status to CMS;
• Support optional wireless ding-dong” doorbell;
• Alarm system can be armed/disarmed by phone call, or SMS, or wireless remote controller, or host keypad, or wireless operation keypad
• System works with AC\DC power supply and built-in high energy lithium battery, system will give notification when low voltage, landline is cut and low power supply happen;
• “Black Box “functions, system can store max 99 alarm records and 100 operation records;
• ·Host is compatible with Contact ID protocol, suitable to build CMS (Central Monitoring Station);
• Rechargeable lithium battery: 7.4v1200m

7 inch touch screen alarm system menu

(Here is the default version in English language)

If you need the version except English, please contact us or send us message when ordering, or we will send the default English.

One host only supports one language. User can not change lanaguage freely.

Technical Parameters

Note:

1) This alarm host also have version of pure PSTN(telephone landline) and dual-network GSM+PSTN. If you need ,please contact us. The version with dual-network GSM + PSTN has 31 wireless (each zone supports max 4 wireless sensors),compatible with optional wireless siren and 2 wired zones

2) This alarm host is only 868MHZ, so the frequency of its accessorie must be also 868MHZ.

But the accessories as follow have both 433MHz and 868 MHz, you can purchase the 433MHZ accessories to

use with other alarm panels at 433MHz.

Related accessories

• Features

  1. To control the alarm host to arm home/arm away/disarm the alarm system.
  2. Press emergency button to send emergency alarm for urgent help

  Specifications

  1. Power supply: disposable alkaline battery 12V27A
  2. Emitting distance: ≥100m (in open area)
  3. Service life of battery: ≤ 1 year
  4. Static current: N/A working current: 15mA
  1. Wireless frequency: 868MHz or 433MH



• wireless door/window sensor

Specifications

1. Power supply: rechargeable lithium battery 3.7v200mAH
2. Wireless frequency: 433MHz or 868MHz
3. Emitting distance: ≥100m (in open area)
4. Service life of lithium battery: ≤3 year (rechargeable)
5. Alarm distance: <4cm
6. Static current: 15μA working current: 15mA

• Wireless wide range PIR detector

Feature

1. Artistic design;
2. Microcomputer intelligent control, anti-electromagnetic interference, anti white light inference;
3. Tamper alarm (Send signal to alarm host and activate alarm);
4. High capacity rechargeable Li-ion battery, long service life, with USB charging port;
5. Mainly monitor and control indoor stereoscopic spaces, generally set as Motion Zone.

Specifications

1. Power supply: disposable battery/rechargeable lithium battery 3.7v800mAH
2. Emitting distance: ≥100m (in open area)
3. Service life of disposable battery ≤1 year, of lithium battery ≤3 years
4. Detecting distance: 110°, 10m*10m
5. Wireless frequency: 433MHz or 868MHz
6. Static current: 50uA working current: 15mA

Wireless DVR motion alarm (PIR sensor with built-in camera)

Technical Parameters :

Power Input:100~240VAC 50HZ/60HZ

Backup Battery:3.7V rechargeable Lithium battery

PIR Detect:Wide-Angle:100° 8 * 8 m

Static Current:< 60mA Working Current:< 110mA

Wireless Frequency:433

Backup Battery Working Time:≤ 3 Hours

Camera:1/6.5” OV CMOS Chip, 300,000 pixel

Video Format:AVI

Recording Speed:30 fps

Resolution:640 × 480,Min. illumination: 0.1 lux

Focal Length: 8mm

Viewing Angle: 35°(Vertical) 60°(Horizonal)

Transmission Mode:USB 2.0(Hs)

Recording Time: 1 minute (can be customized)

Memory Capacity:SD card 4GB(Supports:8G,16G,32G)

Product Dimension:103 * 60 * 32(mm)

Video Play:Windows ME/ 2000/ XP/ Mac OS 9.2.2 or higher version(Windows98 requires driver installation)

• Wireless Indoor Siren
• Features

1. Works with alarm host, receives wireless alarm signals from alarm host; spot alarm with sound and flash;
2. Usually for indoor use.
3. Power supply type is optional, with disposable battery type, or with rechargeable lithium battery type;
4. Maximum alarm time 3 minutes;
5. Color: Blue/ Red (optional)

Specifications

1. Power supply: 100VAC~240VAC+rechargeable lithium battery 3.7v800mAH or 100VAC~240VAC;
2. Receiving distance: ≥100 M(In open area);
3. Service life of lithium battery ≤3 years;
4. Static current: <15mA working current: <200mA;
5. Wireless frequency: 433MHz or 868MHz;
6. Charging time: ≤12H;
7. Product size: 105mm*65mm*35mm;

• Wireless Smoke sensor

Features:

1. Smart design,beautiful artist and easy installing.

2. Intellectual single chip process and steady and credible self-testing.

3. photo-sonic alarming and restore automatically

4. Connection pole design,convenience,fastness and shortcut

5. suited to use it solely or fit on the wireless electroplate module to use with the wireless control system

Specification:

• Power: 9V battery
• Static Current: <20 uA
• Alarm Current: <25mA
• Alarm output: photo-sonic alarm
• Alarm volume: ≥95db
• Operated temperature: -10 to 45°c
• Operated humidity:<97%
• Size: R=5.25(cm)
• H=3.2(cm)

LED indicator:

• Self-testing condition: lighting one time every 1.67s
• Monitoring condition: light one time every 40s
• Alarming condition: lighting one time every seco

• Wireless gas sensor

Features:

1. Be sensitive to gas/natural gas/liquid oil gas.
2. Safety design,signal-chip intelligent process and temperature compensation automatically. Low false alarm and reliable self-inspection.
3. Alarming with sound and flash and restoring automatically.
4. Available to work alone or work as an accessory of an alarm system.

• wireless LED password keypad

Frequency:433MHZ / 868MHZ for optional

Firmly built with exquisite appearance design
LED displays, intelligent microcomputer chip controls, stable and reliable performance
Work with wireless alarm host to Arm/Arm away/Disarm system by code
Non-volatile chip, info will be stored automatically when power is off

• wireless LCD password keypad

LCD display, touchable panel
Arm/Disarm system remotely and display the host’s situation synchronously
Low voltage alarming
System includes: operation panel, power supply

Drived by 110VAC-240VAC
433MHz and 868MHz are optional
Wireless signal transmitting distance ≥100M

Additional accessories are optional based on your requirements.
