Free shipping 868MHZ Smart home security alarm panel , support IOS Android APP 7 inch touch screen GSM alarm system

Free shipping 868MHZ Smart home security font b alarm b font panel support IOS Android APP
Click to see details
Free shipping 868MHZ Smart home security alarm panel support IOS Android APP 7 inch touch screen
60 % of buyers enjoyed this product!
Availability: in stock
Price:  US $239.00 / piece
Sale price:  US $224.66 / piece


from AliExpress

45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Share:

868MHZ Smart home security 7 inch touch screen GSM alarm system support IOS Android APP, door sensor, PIR sensor , alarm panel with long life Li-ion battery,PIR sensors, strobe siren

Function Features

This is a pure GSM alarm system host with a 7 inch color touch screen and with smart sensors + rechargeable lithium battery.

  • Calendar and clock function; pure GSM alarm system
  • Touch screen alarm system, friendly interface 7 inch color screen displays icons and words;
  • Optional languages: traditional Chinese/ simplified Chinese/ English/ German/ French/ Russian/ Hebrew, etc. can meet different market requirements; except English/Chinese, other language need customized.
  • Up till May of 2014, it has 4 versions of 4 languages for option: English, German, Italian,Dutch. One host only supports one language.
  • Alarm info transferring by GSM network (4 Bands: GSM 850/900/1800/1900MHz) in the form of phone call, SMS;
  • Alarm System has 31 wireless zones (each zone supports max 4 wireless sensors),compatible with optional wireless siren and 8 wired zones; The 8 wired zones can be optional .Its original version has no 8 wired zones. If you need the version with 8 wired defense zones, pls contact us.
  • In system can preset max 5 groups phone numbers, alarm call will be in first priority if a normal call is going; GSM module will send alarm info once the landline cable is cut; Every group telephone number can be individually set to transfer alarm info by SMS or phone call;
  • Zone detection notification in disarm status, system can monitor the track of kids;
  • In system menu you can set Pass By ON/OFF, zone type, Entry Delay ON/OFF for each zone;
  • Smart-logical analysis technology, zone name, installation position and sensor name will be displayed when system alarms;
  • Learn sensors into alarm host by friendly interface;
  • System has non-volatile chip, information will be stored automatically if power is off;
  • Optional smart functions, including check door\window status or voltage status automatically,low voltage of host or sensor alarm, uploads low voltage status to CMS;
  • Support optional wireless ding-dong” doorbell;
  • Alarm system can be armed/disarmed by phone call, or SMS, or wireless remote controller, or host keypad, or wireless operation keypad
  • System works with AC\DC power supply and built-in high energy lithium battery, system will give notification when low voltage, landline is cut and low power supply happen;
  • “Black Box “functions, system can store max 99 alarm records and 100 operation records;
  • ·Host is compatible with Contact ID protocol, suitable to build CMS (Central Monitoring Station);
  • Rechargeable lithium battery: 7.4v1200mAH

7 inch touch screen alarm system menu

(Here is the default version in English language)

Technical Parameters

Power supply: 110VAC~240VAC (adaptors meet different types in world,such as US type, EU type,UK type, AU type)

Rechargeable lithium battery: 7.4v1200mAH

GSM Frequency: 4 bands GSM850/900/1800/1900Mhz

Working condition: temperature range -10~50

Chumidity range<80%

Static current≤140mA, Alarm current≤500mA

Wireless frequency :Only 868MHz, (no 433MHZ &315MHZ)

Support max 8 wireless remote controllers, and max other 116pcs wireless sensors

Host dimension: 220mmX190mmX28mm

Note:

This GSM alarm host is only 868MHZ, so the frequency of its accessorie must be also 868MHZ.

But the accessories as follow have both 433MHz and 868 MHz, you can purchase the 433MHZ accessories to

use with other alarm panels at 433MHz.

Packing list:

GSM alarm system main unit X 1
English User manual X 1
Built-in standby battery X 1
Adaptor X 1
Remote control X4
Door / Window Sensor X 6
Wireless PIR Detector X 3
Wireless strobe siren x 1 (with built-in battery&singal repeator)

Kindly Remind:

We also do wholesale business. You are welcomed to be our distribution partner.

Our Skype: cosinetx

Related accessories

  • Wireless Remote Controller

Features

  1. To control the alarm host to arm home/arm away/disarm the alarm system.
  2. Press emergency button to send emergency alarm for urgent help

Specifications

  1. Power supply: disposable alkaline battery 12V27A
  2. Emitting distance: ≥100m (in open area)
  3. Service life of battery: ≤ 1 year
  4. Static current: N/A working current: 15mA
  5. Wireless frequency: 868MHz or 433MH
  • door/window sensor

Specifications

  1. Power supply: rechargeable lithium battery 3.7v200mAH
  2. Wireless frequency: 433MHz or 868MHz
  3. Emitting distance: ≥100m (in open area)
  4. Service life of lithium battery: ≤3 year (rechargeable)
  5. Alarm distance: <4cm
  6. Static current: 15μA working current: 15mA
  • Wireless wide range PIR detector

Feature

  1. Artistic design;
  2. Microcomputer intelligent control, anti-electromagnetic interference, anti white light inference;
  3. Tamper alarm (Send signal to alarm host and activate alarm);
  4. High capacity rechargeable Li-ion battery, long service life, with USB charging port;
  5. Mainly monitor and control indoor stereoscopic spaces, generally set as Motion Zone.

Specifications

  1. Power supply: disposable battery/rechargeable lithium battery 3.7v800mAH
  2. Emitting distance: ≥100m (in open area)
  3. Service life of disposable battery ≤1 year, of lithium battery ≤3 years
  4. Detecting distance: 110°, 10m*10m
  5. Wireless frequency: 433MHz or 868MHz
  6. Static current: 50uA working current: 15mA

  • Wireless Indoor Siren
  • Features
  1. Works with alarm host, receives wireless alarm signals from alarm host; spot alarm with sound and flash;
  2. Usually for indoor use.
  3. Power supply type is optional, with disposable battery type, or with rechargeable lithium battery type;
  4. Maximum alarm time 3 minutes;
  5. Color: Blue/ Red (optional)

Specifications

  1. Power supply: 100VAC~240VAC+rechargeable lithium battery 3.7v800mAH or 100VAC~240VAC;
  2. Receiving distance: ≥100 M(In open area);
  3. Service life of lithium battery ≤3 years;
  4. Static current: <15mA working current: <200mA;
  5. Wireless frequency: 433MHz or 868MHz;
  6. Charging time: ≤12H;
  7. Product size: 105mm*65mm*35mm;
  • Wireless waterproof strobe siren

1. Unique,elegant,water proof;

2. Microcomputer digitally controlling,

Steady function, super quality;

3. Connect 10 wireless alarm host at most;

4. Inbuilt circuit for charging back-up battery,

5. AC/DC both available which change automatically.

6.Small consumption when not alarming,low voltage

Checking automatically,charging power automatically all hanging installation;

Technical prameter:

1,Power:110~240VAC,50Hz

2,Consumption when not alarming:≤40 mA

3,Consumption when alarmg:≤450 mA

4,Alarming last for 3 minutes

5,Signal receiving distance:≥150M(hollow space)

  • Wireless Smoke sensor

Features:

1. Smart design,beautiful artist and easy installing.

2. Intellectual single chip process and steady and credible self-testing.

3. photo-sonic alarming and restore automatically

4. Connection pole design,convenience,fastness and shortcut

5. suited to use it solely or fit on the wireless electroplate module to use with the wireless control system

Specification:

  • Power: 9V battery
  • Static Current: <20 uA
  • Alarm Current: <25mA
  • Alarm output: photo-sonic alarm
  • Alarm volume: ≥95db
  • Operated temperature: -10 to 45°c
  • Operated humidity:<97%
  • Size: R=5.25(cm)
  • H=3.2(cm)

LED indicator:

  • Self-testing condition: lighting one time every 1.67s
  • Monitoring condition: light one time every 40s
  • Alarming condition: lighting one time every second
  • Wireless gas sensor

Features:

  1. Be sensitive to gas/natural gas/liquid oil gas.
  2. Safety design,signal-chip intelligent process and temperature compensation automatically. Low false alarm and reliable self-inspection.
  3. Alarming with sound and flash and restoring automatically.
  4. Available to work alone or work as an accessory of an alarm system.

Specification:

1. Operating power: 230VAC +/-10%

2. Alarming density: gas: 0.1% ~ 0.3%, natural gas: 0.1% ~0.5%

liquid oil gas: 0.0% ~ 0.3%

3. Operating temperature: -10 to 45 °c

4. Operating humidity:≤97%

5. Alarm volume:≥95db

6. Respond time:≤20s

7.Renew time:≤20s

8. Size :11.5×7×4(cm)

9. Material: ABSV0

  • wireless LED password keypad

Frequency:433MHZ / 868MHZ for optional

Firmly built with exquisite appearance design
LED displays, intelligent microcomputer chip controls, stable and reliable performance
Work with wireless alarm host to Arm/Arm away/Disarm system by code
Non-volatile chip, info will be stored automatically when power is off

  • wireless LCD password keypad

LCD display, touchable panel
Arm/Disarm system remotely and display the host’s situation synchronously
Low voltage alarming
System includes: operation panel, power supply.

Drived by 110VAC-240VAC, 433MHz and 868MHz are optional

Wireless signal transmitting distance ≥100M
