SD Card Slot 960P HD Mini IP Camera Home Security Pinhole Camera IP Camera Onvif Indoor Security CCTV IP Camera 3.6mm Board Lens


Regard TF Card support mini Pinhole ip camera

this models have:1xRJ 45 interface ,1x dc12v power , build,1x micro sd card slot !

because of mini tf card ip camera , we have different senor&different resoulation !the cost are different all record effect is very good!

we have below senor ! 1/4″ OV9732 CMOS hi3518E 720P Models:TF240CB 1/4 senor 1/3″ AR0130 CMOS hi3518E960P Models:TF240CHB1/3 senor this sku just for models:TF240CHB orders ! for more products infomation ,pls go to page: if you have other requirement ,welcome contact with us free !


SD / TF card camera. Its purpose is to store video motion detection alarm.Its general in 15 senconds/video segments.Ordinary video 15 minutes at most/video segments.If you want to record a video all day .

Recommended to choose NVR storage.


High sensitivity, high signal-to-noise CMOS image sensor

H.264 Compression,three streaming, mobile surveillance; compatible with various smart Phone operating system

Support multiple network protocol TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP and so on

Support :ONVIF 2.0

Support :DDNS and three DDNS

Support :sending email, attaching picture

Support :Alarm picture and record Uploaded to FTP server

Support :Timing captured picture to FTP server

Support :Static IP and DHCP

Support :P2P

Support :privacy mask

Support up to 12 users browsing at the same time(Each stream supports four users

Support remote alarm linkage

Only 1 network port is used for IE Browsing,stream transmiting and command access, convenient for router setting

Main Features:

H.264 Main Profile level

1.0/1.3 Megapixel 1280*720 /1280*960P Resolution Can be optional

Dual H.264 Stream, resolution, frame rate, bit rate adjustable

Onvif Compliant compatible with brand NVR such as Hikvision, dahua,xiongmai

Support plug in & play,

indoor Use for hide ip camera

This IP hide ip camera is one cost effective H.264 1.0 Mega Pixel IP wifi camera, which HI3518E chipset, adopts H.264 Main Profile @ Level3 compression technology. Meanwhile it uses 1/4″ inch progressive CMOS sensor, plus with 1.0 megapixel lens, ensure its high quality image.size is 40X40MM

H.264 Main Profile

1.0 Megapixel 1280*720p Resolution
Dual H.264 Stream, resolution, frame rate, bit rate adjustable

support Onvif Version: 2.0

Technical Specifications



1.3MP 960P(TF240CHB)

System Structure

Embedded RTOS,dual-core 32bit DSP(Hi3518E),pure hard compression,watchdog

Image sensor size+dsp

1/4″ OV9732 low lux CMOS senor HI 3518E+OV9732

1/3″ AR0130 Ultra-low-illumination

CMOS sensor Hi 3518E+AR0130

Min illumination

Color 0.1Lux F1.2;

B/W 0.1 Lux F1.2;

Color 0.1Lux F1.2;

B/W 0.01 Lux F1.2;

Video Processing

H.264,support dual-stream,AVI; 0.1M~6Mpbs variable; 1~30f/s variable;

Image output

Main stream:1280*720;

Sub-stream:704*576;720P VGA,QVGA

Main stream:1280*9601280*720;


Audio interface

1ch intput,level 2Vp-p, impedance 1kΩ, support sound pick-up input;1ch output,level 16Ω,30mw,support earphones or amplifier;

Audio Processing

G.711, support bidrectional talk,audio&video synchronization;

Network interface


photo resistance

A photo resistance interface, support photo resistance input signal and image,IR-CUT, infrared light linkage;


support micro sd card slot storage



Standard intelligent video analysis functions

Service functions

Support WEB,OSD,live video transmission,support motion detection and IO alarm center reminders as well as screen pop-up linkage; JPEG capture;unified client remote monitoring software,Hip2p


Support onvif 2.0 version

Mobile monitoring

Support mobile monitoring(iPhone,,Android) by app camhi


DC12V power input interface




Support POE power supply(optional contact us for custom )

Package Include:

1 x Mini IP Camera models:TF240CHB 1 x Bracket 1x instruation Note: Software will be sent to your emails or leave message in aliexpress when you paid!pls contact with our SALES team if you need !

If the buyer want other size lens please ‘Leave Message to Seller’ to notify us when bidding.

Simple Instruation:

To Customers :

Thanks for your attention to our products.if you have any question ,pls fell free to contact with us !

we will replyed you within 24hours!!!

Below Lens,some of them can be replaced for different angle view &distance requirement ! pls talk with us whether it is available for the camera !
